FL 1500 C DMX Dual 3000K CRI 90+

Item no.
Categories:

Light generator designed for end lights and sidelight fibres where colour and twinkle effect is required. Typical fields of application: interior as well as exterior lighting, big starry sky ceilings, works of art, entrances, big rooms, lobbies, canopies, fountains, swimming pools, indication lights and façade lighting. FL 1500 DMX C Dual features a DMX controlled colour and twinkle wheel and very smooth dimming. Additional features are instant-on and hot restrike. Colour wheel and twinkle wheel versions as well as dimmable white light versions are also available. All versions are available in an outdoor series.

Connector sizeØ28
Fiber typePMMA / Glass
Size309x305x150 mm
ColourBlack
Supply voltage100-240 V / 50-60 Hz
Light source power100 W
Total power115 W
Main fuseIntegrated auto.
Power cordCord set w/ earthed connector
Data connection3,5 mm phone/jack DALI
Driver typeLED Driver CC
Driver life>100,000 hrs
Thermal protectionIntegrated auto
Ventilator typeDC axial fan
Fan noise level30 dB(A)
Fan life40000@60°C (L90) hrs
Max. ambient temperature45 °C
Min. ambient temperature-10 °C
Light sourceLED
Light source lifetime>35.000 h
Light source manufacturerNichia
Light source colour temperature3,000 K
Light source CRI90+
Lumen maintenanceL 70
Operating environmentIndoor / dry locations
Protection ratingIP 20
MaterialAluminium and plastic
Weight4 kg
Surface treatmentAnodised

Show all
Title Item
CTC filter -1000K Ø28 01261019
CTC filter -1200K Ø28 01261020
CTC filter -900K Ø28 01261021
CTC filter +2000K Ø28 01261022
CTC filter +1000K Ø28 01261023
Mounting Kit FL 1500 C 01369001
DMX 512 Sunlite control unit, USB 01600302
DMX 512 Sunlite control unit, IP 01600303
FL 1500 XT filter holder 49001530
Adaptor Ø28/Ø9 78000130
DMX cable 5 m XLR plugs 99030052
DMX cable 2.5 m XLR plugs 99030056
DMX cable per metre 99030055
DMX 512 splitter 01600310
Title Item
Fan replacement kit 01308000
