Specification Port Connector Size Ø30 mm standard port (Up to Ø28 mm fibre core diameter) Fibre Type PMMA / Glass Material Black Hard Anodized Aluminium Mains Supply Voltage 100-277V / 50-60Hz Total Power Consumption 105 W LED Power Consumption 100 W LED Lifetime (L80) > 60,000 hours LED Driver Lifetime > 100,000hours (@ Tc 70°C at 80% load) Control System 0/1-10V (DMX, DALI/DALI-2, D4i, PWM, and Casambi upon request) Thermal Protection Automatic resettable Protection Rating IP68 (External LED Driver rated IP67) Cooling System Natural Convection Ambient Temperature -10°C to 50°C Applied LED Nichia CCT (Nominal) 3000K CRI (Ra) Typical Value 93 Weight 8.3 kg
FL 1500 XT268M 3000K CRI 90+
High-Power Waterproof Light Generator for Outdoor and Fiber Optic Applications
The The FL 1500 XT268M Series is a premium, high-power light generator featuring an IP68-rated enclosure, engineered for outdoor and demanding environments. Designed to deliver enhanced high-lumen output, it offers exceptional performance, durability, and long-term reliability in challenging conditions. Optimized for compatibility with PMMA and glass fiber optic lighting systems, the series provides precise and dependable illumination for a wide range of professional applications.
The FL 1500 XT268M supports smooth, flicker-free dimming and offers extensive control flexibility through 0/1–10 V, PWM, DMX, DALI/DALI-2, D4i, Casambi, and potentiometer interfaces, ensuring seamless integration with modern lighting control systems. With a high Colour Rendering Index (CRI), it delivers excellent light quality, accurate color reproduction, and optimal visual comfort.
Available in Warm White, Neutral White, Cool White, Tunable White, and RGBW, with custom configurations available upon request, the series features a wall-mounted design, energy-efficient operation, and robust construction, making the FL 1500 XT268M Series a powerful, versatile, and reliable solution for demanding professional lighting installations.
