Size Ø26 x min. 200 mm - max. 2150 mm Colour Grey Supply voltage 24 V DC Total power 1 - 13 W Driver mode Constant Voltage Dimmable Yes LED efficacy 100 lm/W Thermal protection Integrated auto Max. ambient temperature 45 °C Min. ambient temperature -20 °C Light source LED Light source lifetime 50,000 h Light source manufacturer Xicato Light source catalogue number XLT Light source colour temperature 3,000 K Light source CRI 98 Light source CRI-8 (Ra) 98 Light source CRI-14 97 EMC marking Ja UV (200-400 nm) <1 µW/lm UV-A (380-320 nm) <1 µW/lm UV-B (320-280 nm) <1 µW/lm Lumen maintenance L70 B0 efter 50.000 timer Temperature Measurement Point Backside center of conduit Surface temp. increment above ambient 30 °C Max. LED junction temp 100 °C Max.LED junction temp.Manufacturer data 120 °C Operating environment Indoor / dry locations Protection rating IP 20 Cleaning Dry cloth only Material AlMgSi0,5 6063 + POM + ABS Weight 800 g per m conduit Fixture luminous flux 720 lm/m Surface treatment Anodised Optics Diffusor Rotate ±150° Mounting Surface mounted with nut or screws Mounting hole Ø19 mm Built-in height 34 mm Cable type AWG 18 Plug type TE AMP
XPO X-LED Horizontal Ø8 mm legs grey
XPO X-LED Horizontal is the perfect choice for your interior environment if you are aiming for a sublime light in your showcases, niches, exhibition or display areas. It includes a warm white light solution and it has high colour rendering. Dimmable options are also available. The finish is black or grey. Other finishes are obtainable on request. XPO X-LED Horizontal stands on 8mm legs and can be mounted on vertical or horizontal surfaces. Its measurements are customised according to your specific needs.
| Title | Item | |
|---|---|---|
|
XPO-led cover flange black | 11160010 |
|
XPO-led cover flange grey | 11160020 |
|
XPO-led cover flange with screws black | 11160110 |
|
XPO-led cover flange with screws grey | 11160120 |
|
XPO-led cover flange 2 parts black | 11160210 |
|
XPO-led cover flange 2 parts grey | 11160220 |
|
XPO-led mounting clips 10 pcs black | 11160310 |
|
XPO-led mounting clips, 10 pcs, grey | 11160320 |
|
XPO-led mounting bracket, 10 pcs, black | 11160410 |
|
XPO-led mounting bracket, 10 pcs, grey | 11160420 |
|
Driver set 15W for XPO X-LED | 11480022 |
